FAS discharge flap belt conveyor GF 1380-800-600

Preview: FAS discharge flap belt conveyor GF 1380-800-600

FAS discharge flap belt conveyor GF 1380-800-600

€3,324.00 *

Prices plus VAT plus shipping costs

Delivery time approx. 5-10 days.
Pick up by arrangement.

Order number: RA2419

FAS discharge flap belt conveyor GF 1380-800-600 RA2419 Technical data: Conveyor length... more

Close menu

Product information "FAS discharge flap belt conveyor GF 1380-800-600"

FAS discharge flap belt conveyor GF 1380-800-600

RA2419

Technical data:

Conveyor length (NL): 1380 mm (800 mm conveyor belt + 580 mm flap)
Frame width (NB): 800 mm
Belt width (GuB): 600 mm
Construction height (BH): 435 mm
support feet: optionally available
Conveying speed (v m/s): adjustable between 0,025 and 0,883 m/s with frequency converter
Drive: SEW gear motor
Electrical data: 50Hz V380-500, kW 0.25 lifting and 0.37 conveyor belt
Side guide distance: 655 mm
Maximum recommended package size: 600 x 450 mm

Optionally available:
Supports to increase the delivery height
Frequency converter

Prices net plus VAT. ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg

condition:	good (used)
Conveying length in mm:	1380
Nominal / outside width in mm:	800
Belt width in mm:	600
Driven:	YES
Engine type:	SEW Getriebemotor
KW:	0,25/S1, 0,37/S1
scope of delivery:	including side guides without supports
