Transnorm belt curve conveyor left GKF 90°-600-400-IR1000 - NEW

RA2307

Technical data:
Frame width (NB): 600 mm
Frame width with Bearing cover and motor: 850 mm
belt width (GuB): 400 mm
height (BH): 220 mm
height with motor (MH): 350 mm
Inner radius (IR): 1000 mm
Conveying angle: 90° degrees
Conveying speed (v m/s): 1,0m/s
Drive: SEW motor motor
Electrical data: 50Hz V380-500, kW 0,75 / S1
Year of construction: 2021
Height Sideguides: 194 mm

Optionally available:
Supports
Frequency converter for stepples speed controll

Prices net plus VAT from central warehouse Dr. Sonntag GmbH & Co KG, Gattingerstreet 11 B & C, 97076 Würzburg

Construction year:	2021
condition:	new
Nominal / inner radius in mm:	1000
Nominal / outside width in mm:	600
Belt width in mm:	400
angle:	90°
Driven:	YES
Running direction:	LINKS
Engine type:	SEW Eurodrive
KW:	0,75/S1
Conveyor speed m / s:	1,0
scope of delivery:	including side guides without supports
