Product information "Transnorm Rising falling Incline with arch and forerun belt conveyor 1000+10700+1000-600-500"

Transnorm Rising falling Incline with arch and forerun belt conveyor 1000+10700+1000-600-500

RA2459

Technical data:

Conveyor length (NL): 12700 mm (1000 mm forerun + 10700 mm incline + 1000 mm arch )
frame width (NB): 600 mm, 700 mm with motor
belt width (GuB): 500 mm
Overall height (BH): 80 mm, 430 mm with motor
Supporting feet: optionally available
Conveying speed (v m/s): 0,5
Drive: SEW gear motor
Electrical data: 50Hz V380-500, kW 0,55 S1
Drive drum: Ø = 81 mm
Belt return roller: Ø = 81 mm

Optionally available:
Supports
Side guide on one side and on both sides
Adjust length (longer/shorter)

Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany

Construction year:	2014
condition:	good (used)
Conveying length in mm:	12700 ( 1000 + 10700 + 1000 )
Nominal / outside width in mm:	600
Belt width in mm:	500
Driven:	YES
Engine type:	SEW Eurodrive Zentralantrieb mit Spannstation
KW:	0,55/S1
Conveyor speed m / s:	0,5
scope of delivery:	without supports and side guides
